1,736 Sq Ft Bungalow T-Shaped Single-Story House Plan with 3 Bedrooms, 2 Bathrooms and Carport
222
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
House design concept 59446R is a single-story T-shaped Bungalow with Total Heated 1,736 Sq Ft, 3 bedrooms and 2 bathrooms, designed for a family of 3-4 people. Brick exterior walls give the facade a durable, low-maintenance finish, and the hip and valley roof with a 6/12 (26°) pitch sheds rain and snow quickly. The footprint measures 58'2" wide by 65'5" deep.
The entry leads into an open floor plan where the great room and kitchen share one space, so the family stays together while meals are prepared. The large great room is anchored by a fireplace for winter evenings, and floor-to-ceiling windows fill it with daylight. The large kitchen is backed by a walk-in pantry that keeps supplies out of sight, and the breakfast nook suits quick everyday meals. A home office on the same level offers a quiet place for remote work or study.
All bedrooms are on one level and clustered together, keeping parents close to the children. The primary bedroom has a walk-in closet that frees the room from bulky wardrobes. Two full bathrooms serve the household, the laundry on the main floor simplifies daily chores, and the utility room keeps technical equipment apart from the living spaces.
Covered rear and side porches let the family spend time outdoors even in the rain. The front-entry carport shelters one car and takes little space on the lot. The main foundation is bored piles, with slab, strip footing or block foundations as options to suit the soil; the exterior walls are built of sand-lime block, with aerated concrete, ceramic block or timber frame as alternatives. The project offers Total Heated 1,736 Sq Ft, 3 bedrooms, 2 bathrooms and a one-car carport.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 8,683
My Home Floor Plans Rosemead US$ 1,300
Plan & Simple LLC Austin US$ 3,473
