2,439 Sq Ft Minimalism H-Shaped Single-Story House Plan with Basement, 3 Bedrooms, 3 Bathrooms and Carport
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
House design concept 63652C is a Minimalism single-story, H-shaped single-family home with a basement, a total heated area of 2,439 Sq Ft, 3 bedrooms and 3 bathrooms, designed for 3-4 people. The H-shaped footprint, 58'4" wide and 80'2" deep, is covered by a flat roof and finished in stucco and wood, which gives the house a clean, calm outline. A carport for two cars sits beside the house.
The entry leads into an open floor plan where a large great room and a large kitchen share one space. The kitchen has an island, a breakfast bar and a breakfast nook for everyday meals, while a walk-in pantry keeps supplies out of sight. Panoramic windows, window walls and floor-to-ceiling windows fill the day zone with daylight and open views to the covered rear porch.
All bedrooms are on one level and clustered together, which keeps parents close to the children. The main floor primary suite includes a walk-in closet, and three full bathrooms shorten the morning wait. A utility room and storage keep household equipment in order.
The covered porch gives shelter from sun and rain, and the courtyard creates a private outdoor spot for relaxing. The basement adds extra space below the main floor. The house rests on continuous footings, with a slab or block foundation as options, and the walls can be built from aerated concrete, ceramic block or sand-lime block. In figures: total heated area 2,439 Sq Ft, 3 bedrooms, 3 bathrooms and a 2-car carport.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 12,196
My Home Floor Plans Rosemead US$ 1,600
Plan & Simple LLC Austin US$ 4,879
