2,218 Sq Ft Transitional 2-Story House Plan with 3 Bedrooms and 3 Bathrooms
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
Digital house design concept 93623C is a transitional 2-story single-family home with a total heated area of 2,218 Sq Ft, 3 bedrooms and 3 bathrooms, designed for 3-4 people. A low-slope shed roof keeps the silhouette clean and simple, while the layout separates the shared living areas on the main floor from the private bedrooms upstairs.
The open floor plan joins a large family room with a fireplace and a large kitchen into one great room, so cooking, meals and evenings together happen in the same space. A corner window brightens the kitchen and its breakfast nook for quick meals, and the walk-in pantry keeps supplies organized and off the counters. Large and floor-to-ceiling windows bring daylight deep into the living areas, and the home office offers a quiet place to work or study.
Upstairs, the primary bedroom and the two secondary bedrooms are clustered together, keeping parents close to the children at night. The walk-in closet in the primary bedroom frees the room from bulky wardrobes. Three full bathrooms shorten the morning rush, and a utility room keeps household equipment in one place.
A covered side porch offers a sheltered outdoor spot in any weather, and a balcony adds a private place for fresh air. The exterior combines stone/brick veneer, wood and stucco for a textured facade. The house rests on strip footings, with a slab or concrete block foundation as options, and the exterior walls are aerated concrete, with clay block or calcium silicate block as alternatives. The footprint is 48'2" wide and 38'6" deep. In figures: Total Heated 2,218 Sq Ft, 3 bedrooms and 3 bathrooms.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 11,091
My Home Floor Plans Rosemead US$ 1,450
Plan & Simple LLC Austin US$ 4,437
