1,897 Sq Ft Traditional L-Shaped 1.5-Story House Plan with 3 Bedrooms, 1.5 Bathrooms and 2-Car Garage
222
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
Digital house design concept 53551R is a Traditional L-shaped 1.5-story single-family home with a total heated 1,897 Sq Ft, 3 bedrooms, 1.5 bathrooms and a 2-car garage. Its gable roof with hip-and-valley sections and dormers at a 10/12 (40°) pitch makes the half story usable, and the layout suits 3-4 people.
The front entry opens into a closed floor plan that keeps each room quiet and warm. The large family room gives space to gather, and the large separate kitchen includes a breakfast nook for everyday meals. A home office offers a dedicated workplace, and a corner window brings in daylight from two sides.
The primary suite sits on the second floor with a walk-in closet for organized storage, and split bedrooms keep it apart from the other two bedrooms. Laundry on the main floor saves trips up the stairs, while the utility room and storage keep equipment out of sight.
A deck extends living outdoors, and the front-entry 2-car garage faces the street for a short driveway. Stone/brick veneer and wood give the facade durability and warmth. Bored piles are the main foundation, with slab, strip or block options; walls are silicate block, with aerated concrete, ceramic block or timber frame as alternatives. The house is 49'7" wide and 43'8" deep, with a total heated 1,897 Sq Ft, 3 bedrooms, 1.5 bathrooms and a 2-car garage.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 9,485
My Home Floor Plans Rosemead US$ 1,300
Plan & Simple LLC Austin US$ 3,794
