2,163 Sq Ft Modern Narrow Lot 2-Story House Plan with 3 Bedrooms, 3 Bathrooms and 2-Car Garage
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
House design concept 57448C is a modern narrow lot 2-story single family home of Total Heated 2,163 Sq Ft with 3 bedrooms, 3 bathrooms, a 2-car garage and a flat roof. The facades combine wood, stucco and tile, and a footprint of 28'6" wide by 72'4" deep fits the house onto a narrow lot. The layout suits a household of 3-4 people.
The entry leads into an open floor plan where the large great room is open to below, so floor-to-ceiling windows and window walls carry light through the full height of the day zone. The large kitchen centers on an island with a breakfast bar, keeping the cook in touch with the family, and the breakfast nook by a corner window serves everyday breakfasts. A home office keeps work apart from family life, and panoramic windows face the deck.
Upstairs, the clustered bedrooms keep the family close together. The primary suite on the second floor has a walk-in closet that frees the room of wardrobes, and a balcony offers private outdoor space. Three bathrooms shorten the morning rush, and the utility room keeps household equipment away from the living areas.
The front entry 2-car garage shortens the way from the street on a narrow lot and carries a garage rooftop deck for extra outdoor living. The base foundation is strip footings, with a slab or block foundation as options; the exterior walls are aerated concrete, with ceramic hollow block or sand-lime block as alternatives. The project is available for purchase as a digital house design concept: Total Heated 2,163 Sq Ft, 3 bedrooms, 3 bathrooms and a 2-car garage.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 10,816
My Home Floor Plans Rosemead US$ 1,450
Plan & Simple LLC Austin US$ 4,327
