Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
The digital house design concept 60636C is a Traditional 2-story single-family house with Total Heated 2,002 Sq Ft, 5 bedrooms and 2 bathrooms, designed for a narrow lot. At 27'4" wide and 45'8" deep, the house fits a narrow lot. The hip roof with skylights adds daylight inside, and the stone/brick veneer and wood exterior keeps its look for years. The layout serves a family of 6-8 people.
A covered front porch leads to the entry, which keeps coats and shoes out of the living space. The open floor plan joins the living area and the large kitchen, so the cook stays part of family life. The kitchen has a walk-in pantry for bulk supplies and a breakfast nook for quick everyday meals. Large windows and floor-to-ceiling windows bring daylight deep into the plan.
The primary suite is on the second floor, and the two primary suites give two generations bedrooms of equal standing. The bedrooms are clustered, so parents stay close to the children's rooms. Two full bathrooms serve the five bedrooms, while the laundry, the utility room and the storage room keep household work and seasonal items in order.
A deck extends living outdoors in the warm season. The house rests on strip footings, with a slab or a block foundation as options, and the exterior walls are built of aerated concrete blocks, with ceramic hollow blocks or sand-lime blocks as alternatives, so the build can follow the site and local practice. In total, the plan offers Total Heated 2,002 Sq Ft, 5 bedrooms and 2 bathrooms.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
