2,041 Sq Ft Traditional Narrow Lot 2-Story Family House Plan with 4 Bedrooms and 3 Bathrooms
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
House design concept 73942C is a Traditional narrow lot 2-story single family home with Total Heated 2,041 Sq Ft, 4 bedrooms and 3 bathrooms, designed for a family of 4-6 people. A hip roof with a 6/12 pitch and a skylight brings extra daylight inside, while the stone/brick veneer and stucco exterior stands up well to the weather. With a width of 28'2" and a depth of 56'9", the house fits slim city and suburban lots.
The entry opens into an open floor plan where the great room, dining area and kitchen share one space, so the family stays together while cooking. The large kitchen lets several people work at once, and the breakfast nook serves quick everyday meals.
The primary bedroom is on the second floor, with a walk-in closet that keeps clothes out of the sleeping area. The bedrooms are clustered together, so children sleep close to their parents, and three full bathrooms ease the morning rush. The laundry on the main floor keeps washing noise away from the bedrooms, while the utility room and the storage room hold household equipment and seasonal items.
A covered front porch shelters guests from the rain, and a covered rear porch offers shade for outdoor meals. The project is designed on strip footings, with a slab or a concrete block foundation as options. The exterior walls are of aerated concrete, with clay hollow block or calcium silicate block as alternatives. The house offers Total Heated 2,041 Sq Ft, 4 bedrooms and 3 full bathrooms.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 10,206
My Home Floor Plans Rosemead US$ 1,450
Plan & Simple LLC Austin US$ 4,083
