2,481 Sq Ft Modern 2-Story House Plan with 3 Bedrooms and 3 Bathrooms
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
Design 62207C is a modern 2-story single-family house design concept with Total Heated 2,481 Sq Ft, 3 bedrooms and 3 bathrooms, designed for 3-4 people and available for purchase as a digital house design concept. The square footprint measures 36'9" wide by 49'2" deep, so the house fits a compact lot. The hip and valley roof with a 5/12 (22°) pitch shelters the walls on every side, and wood, stucco and flexible ceramic give the exterior a varied texture.
A portico marks the entry and keeps it dry. The open floor plan joins a large great room with a large kitchen, so cooking and family time share one space. An island and a breakfast bar serve quick meals, the walk-in pantry holds bulk supplies, and a corner window brings in daylight from two sides. Large windows and floor-to-ceiling windows open the great room toward the covered rear porch. A home office on the ground floor gives a separate room for remote work.
The bedrooms are clustered on the upper floor, keeping the family's sleeping area together. The primary suite has a walk-in closet that keeps clothes out of the bedroom. Three full bathrooms shorten the morning rush, and a utility room keeps household equipment away from the living spaces.
The covered rear porch extends the living space outdoors in any weather, and the balcony gives the upper floor its own outdoor spot. The main foundation is strip footings, with a slab or a block foundation as options to suit the soil. The exterior walls are aerated concrete block, with hollow clay block or sand-lime block as alternatives. In figures: Total Heated 2,481 Sq Ft, 3 bedrooms and 3 bathrooms.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 12,407
My Home Floor Plans Rosemead US$ 1,600
Plan & Simple LLC Austin US$ 4,963
