1,474 Sq Ft Bungalow T-Shaped Single-Story House Plan with 3 Bedrooms, 1.5 Bathrooms and 1-Car Garage

Plan
72446C
Lead time 30 days
Signed & Sealed
DC Available
Key Specs
1474
Total Heated ft²
1 + 1
Baths + 1/2 Baths
3 + 0
Beds + Home Office
1
Cars
Projekt Architektoniczny

Opis techniczny

Rzuty kondygnacji

Rzut więźby dachowej

Rzut dachu

Przekroje

Elewacje

Zestawienie stolarki okiennej i drzwiowej

Projekt Konstrukcyjny

Zawiera opis techniczny

Rzuty fundamentów

Płyty stropowe w skali

Rysunki detali konstrukcyjnych

Zbrojenie słupów

Zbrojenie wieńców

Zbrojenie nadproży

Zestawienie stali konstrukcyjnej

Zestawienie drewna na więźbę

Projekt Instalacji

Instalacja wodno-kanalizacyjna

Instalacja ogrzewania

Instalacja gazowa

Instalacja elektryczna

Need to make some changes?

This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.

The architect of this plan is not from your country.

You have two options for modifying this house plan:

1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.

2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.

Floor Plans
Main Floor
Main Floor 12 – 1,474 Sq Ft Bungalow Single-Story House Plan with 3 Bedrooms and 1.5 Bathrooms – 72446C
Full Specs & Features
Area
Total Unheated: 278.57 ft²
Total Heated: 1473.9 ft²
Dimensions
Depth: 57'4" ft
Width: 46'3" ft
Height: 18'6" ft
Garage
Area: 279 ft²
Cars: 1
Front Entry
Foundation
Concrete Stem Wall
Slab (Optional)
Block Stem Wall (Optional)
Exterior Wall Framing
Aerated Concrete Block
Ceramic Block (Optional)
Calcium silicate block (Optional)
Exterior Wall Materials
Stone/Brick Veneer
Stucco
Rooms
Full bathrooms: 1
Half bathrooms: 1
Bedrooms: 3
Utility room
Entry
Kitchen and Dining
Island
Interior Features
Clustered Bedrooms
Open Floor Plan
Large Family Room (>270 ft²)
Large Kitchen (>130 ft²)
Exterior Features
Covered Front Porch
Covered Rear Porch
Corner Window
Large Windows
Floor-to-Ceiling Windows
Architectural Style
Bungalow
European
Traditional
Roof
Roof Area: 3363.08 ft²
Hip & Valley
Roof Pitch: 5/12 (22°)

House design concept 72446C is a single-story Bungalow with Total Heated 1,474 Sq Ft, 3 bedrooms, 1.5 bathrooms and a front-entry 1-car garage. The T-shaped single-family home sits under a hip-and-valley roof with a 5/12 pitch that keeps its profile low, and the layout suits a household of 3-4 people.

The entry opens into an open floor plan where the large family room and the large kitchen form one great room. The kitchen island lets whoever is cooking stay part of the conversation. Large windows, a corner window and floor-to-ceiling windows bring daylight deep into the living space.

All three bedrooms are clustered together on one level, so the private rooms stay in one quiet group. A full bathroom and a half bath serve the household, and the utility room keeps household chores out of the living area.

The covered front porch shelters the entry, and the covered rear porch offers a shaded place to sit outdoors in any weather. The 1-car garage has a front entry for a short, direct driveway. The exterior pairs stone/brick veneer with stucco. The main foundation is strip footings, with a slab or a concrete block foundation as options; the exterior walls are autoclaved aerated concrete, with clay block or calcium silicate block as alternatives. The house is 46'3" wide and 57'4" deep. In figures: Total Heated 1,474 Sq Ft, 3 bedrooms, 1.5 bathrooms and a 1-car garage.

The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
