2,717 Sq Ft Modern 2-Story House Plan with 4 Bedrooms, 3 Bathrooms and 2-Car Garage
Opis techniczny
Rzuty kondygnacji
Rzut więźby dachowej
Rzut dachu
Przekroje
Elewacje
Zestawienie stolarki okiennej i drzwiowej
Zawiera opis techniczny
Rzuty fundamentów
Płyty stropowe w skali
Rysunki detali konstrukcyjnych
Zbrojenie słupów
Zbrojenie wieńców
Zbrojenie nadproży
Zestawienie stali konstrukcyjnej
Zestawienie drewna na więźbę
Instalacja wodno-kanalizacyjna
Instalacja ogrzewania
Instalacja gazowa
Instalacja elektryczna
This house plan can be modified to fit your family’s lifestyle and your lot’s specifics.
You have two options for modifying this house plan:
1. Order modifications from the original architect. Purchase the modified Digital Concept and send it to your local architect to prepare the Construction Documents.
2. Work with your local architect. Purchase the original Digital Concept without modifications, then ask your local architect to make the changes and prepare the Construction Documents.
The 36726C modern house design concept is a 2-story single-family home with Total Heated 2,717 Sq Ft, four bedrooms, three full bathrooms, a 2-car garage and a breakfast nook, sized for 4-6 people. A hip and valley roof with a 5/12 (22°) pitch sheds rain and snow on every side, and the stone/brick veneer and wood exterior gives the facade a durable finish. The footprint is 50'4" wide and 43'5" deep. The project is available for purchase as a digital house design concept.
The entry keeps coats and shoes away from the living spaces. The closed floor plan keeps cooking smells out of the large family room, where a fireplace creates a natural gathering point. The large kitchen pairs a breakfast bar for quick meals with a breakfast nook for family breakfasts, and its corner window brings in light from two sides. Floor-to-ceiling windows and other large windows fill the interior with daylight.
The bedrooms are clustered on the second floor, keeping parents close to the children. The primary bedroom has a walk-in closet that keeps clothing out of sight, and three full bathrooms shorten the morning rush. A storage room and a utility room keep household supplies and equipment in order.
A covered rear porch offers shaded seating in any weather, and the deck adds room for grilling and relaxing outdoors. The front-entry 2-car garage allows a short driveway. Strip footings are the main foundation, with a slab or concrete block foundation as options; the walls are aerated concrete, with ceramic hollow block or sand-lime block as alternatives. In short: Total Heated 2,717 Sq Ft, 4 bedrooms, 3 bathrooms and a 2-car garage.
The concept is supplied as a DWG+PDF file: you hand it to a local architect, who prepares the Construction Documents to the codes and standards of your area.
Advanced Drafting & Design Co. Mooresville US$ 13,587
My Home Floor Plans Rosemead US$ 1,600
Plan & Simple LLC Austin US$ 5,435
